Dimensions (HxWxD) |
|
Weight |
|
Processor |
|
Display |
-
Color Thin Film Transistor (TFT) liquid crystal display
-
Number of Colors: 4096 colors (12-bit) possible (note: only 256 colors or 16 levels of gray-scale can be shown on the display at a time)
-
Viewable Image (WxH)
-
Resolution (WxH): 240 x 320
-
Dot Pitch: 0.24 mm
-
Five-level brightness setting
-
Light sensor for automatic brightness adjustment
-
Touch sensative screen
|
Storage / Memory |
|
Audio |
-
Audio record and playback (play MP3 music or audio programs from the Web)
-
One-touch instant-record button (for voice memos)
-
Integrated speaker, stereo headphone jack
-
Integrated microphone
|
I/O Communications |
-
USB: The iPAQ H3600 Series ships with a USB (UHCI) cradle. This cradle connects to a computer via a Universal Serial Bus (USB) connection. A USB cable is also provided to directly connect the device to a USB port on a PC
-
Infrared: The module supports slow Infrared (SIR), also defined as IrDA 1.0 with a maximum transmission rate of 1.15Mbps
|
Operating System/Software |
-
Microsoft Windows CE 3.0 for Pocket PC
-
Active Sync 3.1 Desktop Synchronization
-
Pocket Outlook (Calendar, Contacts, Tasks, Notes, Web Browser)
-
Office Apps (Pocket Word, Pocket Excel, Microsoft Reader)
-
Voice Recorder
-
File Explorer
-
Handwriting Recognition
|
Power |
-
Battery life up to 12 hours, 950 mAh Lithium Polymer rechargeable battery
-
Full charge takes an average of 3.5 hours
-
AC Adapter Dimensions (HxWxD)
-
Cord Length (approximately): 6 ft / 1.83 m
-
Voltage Range: 100 to 240 V
-
Input Current: 0.3 A
-
Input Frequency: 50 to 60 Hz
-
Output Voltage: 5 VDC
-
Output Current: 2 Amp
|
Input Devices |
-
Stylus
-
Software based keyboard
|
Connectors |
-
Infrared (IrDA 1.2) port
-
Communications port for serial, USB (UHCI), and cradle docking connections
-
100-pin universal connector for Compaq Expansion Pack System
-
Stereo headset jack supporting an earpiece / microphone headset
-
DC jack power connector
|
External Storage |
CF Card Expansion Jacket adds a CF Card Expansion Slot to the iPAQ Pocket PC |
Operating Temperature |
-
32° to 104° F
-
0° to 40° C
|
Operating Humidity |
|
Regulatory Marks |
-
Electrical: FCC Class B, VCCI, CE, C-Tick
-
Safety: CE Marking, C-UL, NOM
|
Miscellaneous Features |
-
Four Customizable Application Buttons and One Touch Instant Record Button
-
Headphone Jack Integrated
-
Front Mounted Microphone and Speaker
- Joystick Controls (Four directional buttons and one center action button)
|
